GATE VALVE NON-RISING STEM CAST IRON

VAN CỔNG TY CHÌM GANG

GATE VALVE NON-RISING STEM CAST IRON

GATE VALVE NON-RISING STEM CAST IRON

Information: Z45T-10 Non-rising stem gate valve

Non-rising stem gate valve

Non-rising stem gate valve generally used to connect or disconnect the piping in the media, it shut down parts (gate)in the vertical plane centerline of the valve channel to give a lift moving. Non-rising stem gate valve can not be used as a regulating the flow of media.

Z45T-10 Non-rising stem gate valve Specification

  • Model: Z45T-10
  • Size: DN50-DN1200
  • Medium: Water,etc.
  • Suitable medium: water, oil, steam and non-corrosive media
  • Working temperature: ≤200℃
  • Nominal pressure: PN10
  • Connection: Russian standard 12815-80
  • Sealing: Russian D9544-93
  • Main Parts material
  • Body, bonnet, and handle: cast iron GG18
  • Disc: cast iron GG≥18
  • Stem: carbon steel +zinc
  • Seal: brass

Các tên gọi liên quan: Van cổng gang ty chìm; Van cổng ty chìm gang; Gate valve cast iron;Gate valve non-rising; van cổng gang; van cổng gang tay quay; van cổng ty chìm tay quay; Non-rising stem; Z45T-10 Non-rising stem
