KITZ GLOBE VALVE SUS304 SCREW ENDS JIS10K, MODEL UCL

VAN CẦU INOX KITZ NỐI REN 10K, MODEL UCL

Model : UCL

Image result for KITZ UCL

Image result for KITZ UCL

Thông tin kỹ thuật10K CAST STAINLESS STEEL,GLOBE VALVES,SCREWED BONNET,INSIDE SCREW,SCREWED ENDS.,END TO END:KITZ STANDARD,END CONNECTION:JIS B0203,WALL THICKNESS:KITZ STANDARD,TEST STANDARD:KITZ STANDARD
1.0MPa:180℃, 200psi. W.O.G.:350°F S.P.
Approvals:
RoHS指令相当品 1/4 -2 inch(8 -50 mm) approved


Water
Air
Shell 2.10*(1/4-2inch,8-50mm) 1.4(1/4-2inch,8-50mm)
Seat 0.6(1/4-2inch,8-50mm)
Back Seat

Test Pressure(MPa) Inspection Standard:KITZ St’d-2

*=Periodic Test
1/4 3/8 1/2 3/4 1 11/4 11/2 2
mm 8 10 15 20 25 32 40 50
