OSAKA RELIEF VALVES LN1NA

Email: info@iwisu.com

Phones: 090.860.1662


Nom.size	ID	A	B	Setting pressure	Mass kg
Nom.size	ID	Ferrule Screw	B	Setting pressure	Mass kg
1.0^S	23	55	254	0.05～0.8MPa	2.7
1.5^S	35.7	70	261	0.05～0.4MPa	3.6
2.0^S	47.8	82	338	0.05～0.5MPa	8.0
2.5^S	59.5	105	369	0.05～0.5MPa
3.0^S	72.3	110	430	0.05～0.26MPa	15.5
3.5^S	85.1	125	437	0.05～0.19MPa
4.0^S	97.6	155	454	0.05～0.14MPa
