CERAMIC LINED Y DIVERTERS

CERAMIC LINED Y DIVERTERS

CERAMIC LINED Y DIVERTERS

Tổng quan:

Công ty IWISU là một trong những công ty hàng đầu ở Việt Nam về phân phối Van với các thương hiệu nổi tiếng trên thế giới như: ANIX, JC VALVE, FOYO VALVE, SAMWOO, BONNEY FORGE, SWISS FLUID, JDV CONTROL VALVE, MARIANI, KITZ, EBRO VALVE

Trong đó sản phẩm LINED Y DIVERTERS được công ty nhập khẩu và phân phối tại Việt Nam.

Chất lượng của LINED Y DIVERTERS không chỉ đáp ứng nhu cầu của khách hàng mà còn mang lại sự tin tưởng, uy tín về sản phẩm do công ty phân phối.

Ceramic Lined Y Diverters widely used in most of the high corrosive and abrasive transmission systems.

Applications:

Since ceramics material have high hardness and excellent strength, Foyo developed Lined Y Diverters, which are widely used in most of the high corrosive and abrasive transmission systems especially for coal fired power plants, steel plants, mining, chemical industry, petro-chemical, polysilicon and metallurgy.

CERAMIC Y DIVERTERSCERAMIC Y DIVERTERS

The following listed are some typical medium in which Lined Y Diverters have been proved to have good performance.

  • Coal powder
  • Silicon powder
  • Fly ash
  • Mining slurry
  • Mining Slag
  • Coal washing
  • Strong acid slurry
  • Paper making Slurry

LINED Y DIVERTERSLINED Y DIVERTERS

Technology Specification:

Type

Lined Y Diverters
Size DN15-DN400(1/2”-16”)
Pressure Rating PN10,PN16,PN25,PN40, PN63, PN100, CL150, CL300, CL600
Jacket Material WCB, CF8, CF8M, CF3M, Hastelloy, Monel, Alloy 20, Titanium
Lining Material ZrO2 Ceramics, Al2O3 Ceramics, Tungsten Carbide, Si3N4, Solid SiC
End Connection

Flange End, Butt Welding End, EN1092-1, DIN 2501, ASME B16.5
