CEBA-CAST BODY FULL LINED CERAMIC BALL VALVE
Tổng quan:
Công ty IWISU là một trong những công ty hàng đầu ở Việt Nam về phân phối Van với các thương hiệu nổi tiếng trên thế giới như: ANIX, JC VALVE, FOYO VALVE, SAMWOO, BONNEY FORGE, SWISS FLUID, JDV CONTROL VALVE, MARIANI, KITZ, EBRO VALVE
Trong đó sản phẩm BODY FULL LINED CERAMIC BALL VALVE được công ty nhập khẩu và phân phối tại Việt Nam.
Chất lượng của BODY FULL LINED CERAMIC BALL VALVE không chỉ đáp ứng nhu cầu của khách hàng mà còn mang lại sự tin tưởng, uy tín về sản phẩm do công ty phân phối.
Series CEBA ceramic ball valves are designed for extreme corrosive and abrasive applications.
BODY FULL LINED CERAMIC BALL VALVE
Technical Description:
Live loaded Packing
Replaceable block-based bonnet
ISO 5211 Mounting Pad
Adjusting packing nut
V-PTFE packing
Anti-blow out stem
Precise casting body- 3 pc body design
Anti-static
Secondary sealing ring design
Low emission body seal gasket
Ceramics-to-Ceramics sealing for Fire safe
Precisionmachined sealing face, Leakage Class VI per FCI 70-2
Much Lower Torque value than metal seated valves
Nano Ceramics-to-Ceramics seal, stable physical and Chemical properties
Hardness of Ceramics is more than 93HR15N
Replaceable ceramic parts
Concentric serrated finish on the ceramic raised face ensure that this surface be compatible with the gasket and provide a high quality seal
BODY FULL LINED CERAMIC BALL VALVE
Product Type
Ceramics seated and lined ball valve
Flanged Ends
Lever, Pneumatic, Electric operated are all optional
Floating ball Design
Pressure Ratings
PN10, PN16, ANSI Class 150
Size Range
DN15~DN150, 1/2″~6″
Temperature Range
-29℃~+200℃
Design Standards
Valve Design: ASME B16.34
Face-to-Face Dimension: ASME B16.10
Flange Ends: ASME B16.5, EN1092-1
Valve Testing: API 598
Valve Allowable Leakage
ANSI/FCI 70-2 Table 1 , Class VI
Applications
Chloride Crystals Containing Iron
Chloride
Hydroxygen Compounds
Gypsum Slurry
Silicone Powder
Pulp Slurry
Fly Ash
Lime Stone Slurry
Mining Slurry
Salt Slurry
Potassium Carbonate
Sulfite Crystals
